Wipro 20W LED RGB Batten Light (DS22000)

esphome:
  name: led-batten
  friendly_name: Led-Batten

esp8266:
  board: esp01_1m
  #restore_from_flash: true
#preferences:
  #flash_write_interval: 2min
# Enable logging
logger:
# Enable Home Assistant API
api:
  encryption:
    key: ""
ota:
  password: ""
wifi:
  ssid: ""
  password: ""
  fast_connect: True
  power_save_mode: none
sensor:
output:
  - platform: esp8266_pwm
    id: red
    pin: GPIO4
    inverted: False
  - platform: esp8266_pwm
    id: green
    pin: GPIO12
    inverted: False
  - platform: esp8266_pwm
    id: blue
    pin: GPIO14
    inverted: False
  - platform: esp8266_pwm
    id: cold_white
    pin: GPIO5
    inverted: False
  - platform: esp8266_pwm
    id: warm_white
    pin: GPIO13
    inverted: False
light:
  - platform: rgbww
    name: Wipro RGB
    default_transition_length: 0s
    red: red
    green: green
    blue: blue
    cold_white: cold_white
    warm_white: warm_white
    cold_white_color_temperature: 6500 K
    warm_white_color_temperature: 2700 K
    id: thelight
    color_interlock: true #Prevent white leds being on at the same time as RGB leds
    restore_mode: ALWAYS_ON #Start with light on after reboot/power-loss event, so that it works from a dumb lightswitch
    effects:
      - random:
      - strobe:
      - flicker:
          alpha: 50% #The percentage that the last color value should affect the light. More or less the “forget-factor” of an exponential moving average. Defaults to 95%.
          intensity: 50% #The intensity of the flickering, basically the maximum amplitude of the random offsets. Defaults to 1.5%.
      - lambda:
          name: Throb
          update_interval: 1s
          lambda: |-
            static int state = 0;
            auto call = id(thelight).turn_on();
            // Transtion of 1000ms = 1s
            call.set_transition_length(1000);
            if (state == 0) {
              call.set_brightness(1.0);
            } else {
              call.set_brightness(0.01);
            }
            call.perform();
            state += 1;
            if (state == 2)
              state = 0;
